Harbor Private Image Repository Setup Guide

This guide is applicable to deploying Harbor on a Linux system using the offline installer package (harbor-offline-installer).

---

Download Harbor installation package

Visit the official GitHub site to download the Harbor offline installer:

https://github.com/goharbor/harbor/releases/download/v2.14.2/harbor-offline-installer-v2.14.2.tgz

Note: Please ensure that the version you download is compatible with your system (such as v2.14.2) and confirm that the file name is correct.

---

Unzip the installation package

Unzip the downloaded .tgz file to the specified directory:

tar xf harbor-offline-installer-v2.14.2.tgz -C /harbor/softwares/

🔧 Assume that you place the software package in the /harbor/softwares/ directory.

---

Modify the configuration file harbor.yml

Enter the unzipped directory and edit the configuration file:

vim /harbor/softwares/harbor/harbor.yml

Configuration item description

Set host name (IP or domain name)

hostname: 10.0.0.101

This is the access address for Harbor, which must be set to a publicly accessible IP or domain name.

Disable HTTPS (only for test environments)

If you don't need HTTPS, you can comment out the relevant configuration:

# https:
#   # https port for harbor, default is 443
#   port: 443
#   # The path of cert and key files for nginx
#   certificate: /your/certificate/path
#   private_key: /your/private/key/path

💡 It is recommended to enable HTTPS and configure certificates in the production environment.

Set administrator password

harbor_admin_password: 123456

The default username is admin, and the password is the value you define here (here it is "123456").

---

Begin installing the Harbor service

Execute the installation script:

./install.sh

The installation process will automatically pull the dependent container images and start the services required by Harbor (such as Nginx, PostgreSQL, Redis, Registry, etc.).

---

Accessing the Harbor page

After the installation is complete, open your browser and visit:

http://10.0.0.101

Username: admin Password: The password you set in harbor.yml (e.g. "123456")

---

Operations after Login (Optional)

After successfully logging in, you can:

• Add Project
• Push/pull images
• Configure user permissions
• View audit logs

---

Troubleshooting of Common Issues

Problem	Reason	Solution
Page cannot be accessed	Port not open	Check if the firewall allows port 80
Error: connection refused	Service not started	Execute docker ps to check container status
Login failed	Password error	Check if harbor_admin_password is correct
HTTPS Error	Certificate Missing	If HTTPS is enabled, please provide a valid certificate path

---

Start/Stop Harbor Service

Start the service

docker-compose up -d

Discontinuation of Service

docker-compose down

---

Upgrade Harbor (Optional)

If you need to upgrade the Harbor version:

1. Download the new version of harbor-offline-installer
2. Replace old version files
3. Modify the harbor.yml configuration
4. Execute ./install.sh to automatically upgrade

---

Supplementary Information

• Harbor supports advanced features such as multi-tenancy, RBAC permission control, image replication, and vulnerability scanning.
• It is recommended to use HTTPS + self-signed or CA certificates in production environments.
• Can be used in conjunction with Kubernetes to achieve CI/CD pipeline integration.

---

Example of file structure

/harbor/softwares/
└── harbor/
    ├── harbor.yml
    ├── install.sh
    └── docker-compose.yml

---

Tips

• If you are a beginner, it is recommended to deploy Harbor in a local testing environment first.
• You can view the specific error information by executing docker logs <container_name>.
• The logs of Harbor are located in the /var/log/harbor/ directory.
